T-ZSTBZ 80-68°C Q5 Wall Mounted Sprinkler – High-Performance Sidewall Fire Sprinkler
When it comes to space-saving and targeted fire suppression in commercial, residential, and public buildings, a top-quality wall mounted sprinkler is essential. CA-Fire Protection, a leading fire safety equipment manufacturer with over a decade of expertise, proudly presents the T-ZSTBZ 80-68°C Q5 upright sidewall —a precision-engineered fire protection solution designed to deliver reliable fire control in areas where ceiling-mounted sprinklers are impractical. Our T-ZSTBZ 80-68°C Q5 stands out for its compact design, directional water distribution, and consistent performance, complying with global safety standards and trusted by major projects worldwide. As a one-stop fire protection solution provider, CA-Fire’s wall mounted sprinkler products are part of a comprehensive portfolio that includes fire sprinkler, fire alarm valves, and intelligent fire hydrants, all crafted to safeguard life and property with uncompromising quality.
What is the T-ZSTBZ 80-68°C Q5 Wall Mounted Sprinkler?
The T-ZSTBZ 80-68°C Q5 is a high-performance upright sidewall engineered specifically for fire protection in spaces where ceiling installation is not feasible or aesthetically undesirable. This wall mounted sprinkler features a unique sidewall design that directs water in a targeted pattern, providing comprehensive coverage for rooms, corridors, and narrow spaces while saving valuable ceiling space. Unlike traditional ceiling-mounted sprinklers, this is installed directly on walls, making it ideal for environments with low ceilings, exposed ductwork, or architectural constraints that limit overhead installations.
As a core product in CA-Fire’s wall mounted sprinkler lineup, the T-ZSTBZ 80-68°C Q5 is equipped with a high-quality glass bulb as the temperature-sensitive element, ensuring reliable activation at 68°C— the critical temperature for early fire detection and suppression. The sprinkler’s flow coefficient (K=80) delivers a balanced water output, effectively suppressing fires in light to moderate hazard areas without causing excessive water damage. Whether protecting hotel rooms, office corridors, residential apartments, or public facilities, this provides consistent and efficient fire suppression. All our wall mounted sprinkler products comply with international standards set by NFPA, UL, and FM, as well as Chinese national standards such as GB, guaranteeing safety and compliance for every project.
Key Features of the T-ZSTBZ 80-68°C Q5 Wall Mounted Sprinkler
The T-ZSTBZ 80-68°C Q5 upright sidewall is built with industrial-grade durability and performance at its core, incorporating advanced features to meet the unique fire protection needs of wall-mounted installation scenarios. Every wall mounted sprinkler undergoes rigorous quality control testing at CA-Fire’s state-of-the-art facility in Quanzhou, China, ensuring it meets the highest standards of reliability and efficiency. Below are the standout features of this premium wall mounted sprinkler:
- Upright Sidewall Design: This wall mounted sprinkler features an upright sidewall configuration, directing water in a precise, fan-shaped pattern to cover rooms and corridors effectively, making it ideal for space-constrained environments.
- Reliable Temperature Activation: Equipped with a high-sensitivity glass bulb that activates at 68°C, the wall mounted sprinkler ensures timely response to early-stage fires, minimizing fire spread and property damage.
- Optimal Flow Coefficient: With a flow coefficient (K=80), the wall mounted sprinkler delivers a balanced water output, providing effective fire suppression for light to moderate hazard areas while reducing water waste.
- Compact and Aesthetic: The wall mounted sprinkler’s compact design minimizes visual impact, blending seamlessly with interior decor in hotels, apartments, and office buildings without compromising performance.
- Durable Construction: Crafted with high-quality metal materials, the wall mounted sprinkler is resistant to corrosion and wear, ensuring long-term performance in indoor environments with varying humidity and temperature conditions.
- Easy Installation: Designed for straightforward wall mounting, the wall mounted sprinkler comes with standard connection threads, allowing for quick and seamless integration into new or existing fire protection systems.
- Targeted Water Distribution: The precision-engineered nozzle of the wall mounted sprinkler ensures uniform water coverage in a directional pattern, maximizing fire suppression efficiency while avoiding unnecessary water damage to non-fire areas.
- Global Standard Compliance: This wall mounted sprinkler meets the requirements of international fire safety standards, including NFPA 13 (Standard for the Installation of Sprinkler Systems), UL certification, and FM approval, guaranteeing safe and reliable operation.
T-ZSTBZ 80-68°C Q5 Wall Mounted Sprinkler Specification
CA-Fire’s T-ZSTBZ 80-68°C Q5 upright sidewall is engineered with precise specifications to ensure optimal performance in wall-mounted fire protection scenarios. Every technical parameter is carefully calibrated to meet the unique requirements of space-constrained environments, providing reliable and efficient fire suppression. Below is the detailed technical specification of the T-ZSTBZ 80-68°C Q5
| Specification | Details |
|---|---|
| Model Number | T-ZSTBZ 80-68°C Q5 |
| Product Type | Upright Sidewall Wall Mounted Sprinkler |
| Core Function | Fire suppression in space-constrained indoor areas |
| Nominal Operating Temperature | 68°C |
| Temperature-Sensitive Element | Glass bulb |
| Flow Coefficient (K) | 80 |
| Connection Thread | R3/4″ (3/4 inch) |
| Installation Method | Upright sidewall mounting |
| Operating Pressure Range (MPa) | 0.35 – 1.2 |
| Maximum Working Pressure (MPa) | 1.6 |
| Protection Area (m²) | Up to 12 – 15 m² (depending on installation height and spacing) |
| Response Characteristic | Standard response |
| Response Index (RTI) | 80 – 360 (m·s)⁰·⁵ |
| Sprinkler Pattern | Fan-shaped directional spray |
| Applicable Medium | Water |
| Operating Temperature Range (°C) | 4 – 70 |
| Compliance Standards | NFPA 13, UL, FM, GB Standards |
| Material | Corrosion-resistant metal |
| Color | Red (corresponding to 68°C activation temperature) |
Customization for T-ZSTBZ 80-68°C Q5 Wall Mounted Sprinkler
At CA-Fire, we understand that every fire protection project has unique requirements. That’s why we offer customization options for the T-ZSTBZ 80-68°C Q5 to tailor it to your specific needs. Our engineering team can adjust parameters such as the operating temperature (available in 74°C, 82°C, 93°C options), connection thread, and flow coefficient to align with your project’s fire risk level, room dimensions, and water supply system. Whether you need a wall mounted sprinkler for high-temperature environments, narrow corridors, or specialized architectural spaces, we can deliver a customized solution that meets NFPA standards and your project’s specific requirements. All custom wall mounted sprinkler products undergo the same rigorous testing and quality control as our standard line, ensuring uncompromising performance and reliability.
Applications of the T-ZSTBZ 80-68°C Q5
The T-ZSTBZ 80-68°C Q5 upright sidewall is a versatile fire protection solution designed for a wide range of space-constrained indoor environments. Its compact design, targeted water distribution, and easy installation make it ideal for areas where ceiling-mounted sprinklers are not practical. The key applications of this wall mounted sprinkler include:
- Hotel Rooms and Suites: Protecting guest rooms in hotels and resorts, where ceiling-mounted sprinklers may be visually intrusive or architecturally impractical.
- Office Corridors and Cubicles: Fire suppression in narrow office corridors, open-plan workspaces, and cubicle areas, providing targeted coverage without cluttering ceiling space.
- Residential Apartments and Condos: Ideal for apartments, condos, and townhouses, where the wall mounted sprinkler blends with interior decor while delivering reliable fire protection.
- Public Facilities: Libraries, museums, and exhibition halls, where the wall mounted sprinkler’s compact design preserves the aesthetic integrity of the space.
- Healthcare Facilities: Patient rooms, clinics, and nursing homes, where the wall mounted sprinkler provides gentle yet effective fire suppression without disrupting patient care.
- Retail Stores and Boutiques: Protecting retail spaces with low ceilings or exposed architectural features, where ceiling-mounted sprinklers are not feasible.
- Educational Institutions: Classrooms, lecture halls, and dormitories, providing reliable fire protection for students and staff in space-constrained environments.
Why Choose CA-Fire’s T-ZSTBZ 80-68°C Q5 ?
With over a decade of experience in the fire protection industry, CA-Fire Protection is a trusted manufacturer of high-quality wall mounted sprinkler systems, serving customers worldwide. Our T-ZSTBZ 80-68°C Q5 upright sidewall wall mounted sprinkler is backed by our commitment to quality, innovation, and customer satisfaction, making it the preferred choice for space-constrained fire protection projects. Here are the key reasons to choose CA-Fire for your wall mounted sprinkler needs:
- Expert Engineering and Manufacturing: Our wall mounted sprinkler products are designed by a team of fire protection experts with extensive industry experience, using advanced production technology and high-quality materials. Every T-ZSTBZ 80-68°C Q5 wall mounted sprinkler is manufactured to the highest standards, ensuring reliable performance and long service life.
- Comprehensive Fire Protection Solutions: As a one-stop provider, we offer not just wall mounted sprinklers, but a full range of fire safety equipment, including foam extinguishing systems, fire valves, and fire hydrants, allowing you to source all your fire protection needs from a single, trusted supplier.
- Global Standard Compliance: Our T-ZSTBZ 80-68°C Q5 complies with international standards such as NFPA, UL, and FM, ensuring compatibility and compliance for projects worldwide. All our products are certified by national fire safety authorities and insured by PICC, providing an extra layer of assurance.
- Rigorous Quality Control: Every wall mounted sprinkler undergoes multiple quality control checks, including pressure testing, flow performance testing, and temperature activation testing, to ensure it meets our strict quality standards. Our state-of-the-art quality control laboratory is equipped with advanced testing equipment to guarantee consistent performance.
- Proven Track Record: CA-Fire’s wall mounted sprinkler products have been installed in thousands of high-profile projects across Asia, Europe, and North America, including Beijing Daxing International Airport, Tencent Qingyuan Cloud Computing Data Center, and Shanghai South MEGA. Our wall mounted sprinkler systems have a proven track record of reliable fire suppression in real-world scenarios.
- Customization and Technical Support: We offer customized wall mounted sprinkler solutions and professional technical support, from project design and product selection to installation guidance and after-sales service. Our team of technical experts is available to answer your questions and provide tailored recommendations to meet your specific fire protection needs.
- Competitive Pricing and Timely Delivery: As a direct manufacturer, we offer competitive pricing for our wall mounted sprinkler products without compromising on quality. Our efficient production and logistics system ensures timely delivery to customers worldwide, minimizing project delays.
Installation and Maintenance of the T-ZSTBZ 80-68°C Q5
Proper installation and regular maintenance are essential to ensure the optimal performance of your T-ZSTBZ 80-68°C Q5 . This wall mounted sprinkler is designed for easy wall mounting, compatible with standard fire water supply pipelines, and comes with clear installation instructions. For installation, we recommend following the guidelines outlined in NFPA 13 and consulting a qualified fire protection professional to ensure correct positioning, spacing, and alignment with the room’s layout.
To maintain the performance of your wall mounted sprinkler, regular maintenance is required:
- Quarterly Inspections: Check the wall mounted sprinkler for physical damage, corrosion, or obstruction; ensure the glass bulb is intact and free of dust, debris, or paint buildup that could affect its activation.
- Annual System Testing: Conduct a comprehensive test of the fire protection system, including pressure testing and flow testing, to ensure the T-ZSTBZ 80-68°C Q5 operates within the specified parameters.
- Replacement of Worn Parts: Replace any damaged or worn components of the wall mounted sprinkler immediately, including the glass bulb or sealing components, to avoid performance issues during a fire emergency.
- Professional Servicing: For complex wall mounted sprinkler systems, we recommend annual professional servicing by CA-Fire’s technical team to ensure full system functionality and compliance with safety standards.
CA-Fire provides a detailed installation and maintenance manual with every T-ZSTBZ 80-68°C Q5 purchase, and our technical support team is available to assist you with any questions or concerns.
Contact CA-Fire for Your Wall Mounted Sprinkler Needs
If you are looking for a reliable, high-performance wall mounted sprinkler for your space-constrained indoor environment, CA-Fire Protection is your trusted partner. Our T-ZSTBZ 80-68°C Q5 upright sidewall is engineered to deliver exceptional fire suppression performance, comply with global standards, and meet the unique needs of space-constrained projects. We are committed to providing fire protection solutions that safeguard life and property, and we serve customers worldwide with professionalism and integrity.
To learn more about the T-ZSTBZ 80-68°C Q5 , request a product quote, or discuss your customized fire protection needs, please contact us using the details below. Our sales team will respond to your inquiry promptly and provide you with all the information you need to make the right choice for your project:
- Email: sales@ca-fire.com
- Mobile: +86 13400715622
- WhatsApp: +86 18150362095
- WeChat: 404863577
- Website: https://www.ca-fire.com
CA-Fire Protection – Your Global Partner for Premium Fire Protection Equipment. Our wall mounted sprinkler products are crafted with passion and precision, ensuring peace of mind for every space-constrained fire protection project, every time.
